Welcome to InstantDFM™ by Bay Area Circuits.

Upload your printed circuit board (PCB) design files and receive an instant Design for Manufacturability (DFM) report. Our free, automated tool identifies possible production issues enabling you to address areas of concern prior to beginning the manufacturing process, saving you time and money!

Getting your DFM results is as easy as 1, 2, 3:

  1. Select your Mask and Silk Colors and Board Thickness
  2. Select your Design Files
  3. Click submit

In most cases you will see your results in less than 1 minute but results may take several minutes to produce so please be patient. You're the impatient type? Don't worry, we'll also send you an email with a link to view your results as soon as they are ready.

(Remember, we're going to send you a link to your results once ready.)
Compressed Gerber RS-274X, Gerber X2 or ODB++ files in .ZIP or .RAR format.

Questions? Suggestions? Praise? We would love to hear from you!
